class: center, middle, inverse, title-slide # Shell, git, and GitHub ## Statistical Computing & Programming ### Shawn Santo --- ## Supplementary materials Full video lecture available in Zoom Cloud Recordings Additional resources - [Getting Started](https://git-scm.com/book/en/v2/Getting-Started-About-Version-Control) Pro Git - [Git Basics](https://git-scm.com/book/en/v2/Git-Basics-Getting-a-Git-Repository) Pro Git - [Git cheatsheet](https://www.atlassian.com/git/tutorials/atlassian-git-cheatsheet) - [Happy Git and GitHub for the useR](https://happygitwithr.com) --- class: inverse, center, middle # Shell --- ## Before we get started... On GitHub: 1. Navigate to https://classroom.github.com/a/WtWjX5K3 to get your own private repository for `cl_demo/`. 2. Navigate to your repository and copy the git repository URL - available by clicking on the green `Code` button. In RStudio: 1. Go to `File > New Project...` 2. Select `Version Control` 3. Select `Git` 4. Paste the git Repository URL into the dialog box 5. Click `Create Project` We will learn to navigate and manipulate files in folder `cl_demo/` using the terminal and shell commands. --- ## Unix and Unix variants .pull-left[ - Unix was an operating system developed at Bell Labs in the early 1970s. - Bell Labs distributed the operating system in its source language form, so anyone who obtained a copy could modify and customize it for their own purposes. - Linux, Mac OS X, Android, iOS, Chrome OS, Orbis OS all use Unix-like operating systems. ] .pull-right[ ![](images/bell_labs.png) .small-text[ *Source*: https://www.bell-labs.com/usr/dmr/www/picture.html ] ] --- ## What is the shell? - A shell is software that provides an interface for an operating system's users to provide access to the kernel's services. - Shells that take commands from the keyboard and give them to the operating system were originally the only interface available on a Unix like system - Today we have both graphical user interfaces (GUIs) and command line interfaces (CLIs). - Many shell variants exist including sh, bash, csh, ksh, and more. ```bash [sms185@numeric1 ~]$ which bash /usr/bin/bash [sms185@numeric1 ~]$ which zsh /usr/bin/zsh [sms185@numeric1 ~]$ which sh /usr/bin/sh ``` --- ## What is the terminal? - A program that accepts input from the keyboard and displays output on the screen. - Also known as a terminal emulator. - The terminal needs the shell. The shell interprets what you input into the terminal. - **Windows users**: use Git Bash for BASH emulation - **Mac OS X and Linux**: use built-in terminal emulator --- ## Why use the terminal and shell? - It may be your only option if working on a high-performance computing cluster - Automate tasks with `cron` - Gain a lot of functionality with minimal keyboard entry - System administration, computer maintenance, and application start-up scripts --- class: inverse, center, middle # Command line basics --- ## Where am I? ```bash [sms185@numeric1 ~/cl_demo]$ ``` - `sms185`: user - `numeric1`: computer (server) name - `~`: home directory - `/cl_demo`: folder `cl_demo` - `$`: signifies I am a regular user as opposed to a root user with `#` To print my working directory (where I am located) use ```bash [sms185@numeric1 ~/cl_demo]$ pwd /home/fac/sms185/cl_demo ``` --- ## Change directories Change directories with command `cd`. Let's move to the home directory, print that directory, then move to directory `cl_demo` and print the working directory once there. ```bash [sms185@numeric1 ~/cl_demo]$ cd ~ [sms185@numeric1 ~]$ pwd /home/fac/sms185 ``` ```bash [sms185@numeric1 ~]$ cd cl_demo/ [sms185@numeric1 ~/cl_demo]$ pwd /home/fac/sms185/cl_demo ``` -- Navigate to your home directory. Then go to `cl_demo/data/` and print the working directory once there. -- Navigate through multiple directories by specifying the complete relative path. --- ## Absolute vs. relative paths An absolute path is defined as specifying the location of a file or directory from the root directory. ```bash [sms185@numeric1 ~]$ cd /home/fac/sms185/cl_demo/ [sms185@numeric1 cl_demo]$ ``` <br/> -- A relative path is defined as the path related to your current working directory. ```bash [sms185@numeric1 ~]$ cd cl_demo/ [sms185@numeric1 cl_demo]$ ``` --- ## Paths diagram example ![](images/paths.png) --- ## Anatomy of a Unix command .tiny[ ```bash *[sms185@numeric1 cl_demo]$ ls -l --all ./ total 88 drwxr-xr-x 6 sms185 prof 7 Aug 18 15:34 . drwxr-xr-x 37 sms185 prof 63 Aug 18 15:34 .. drwxr-xr-x 2 sms185 prof 5 Aug 18 15:34 data drwxr-xr-x 8 sms185 prof 13 Aug 18 15:34 .git -rw-r--r-- 1 sms185 prof 156 Aug 18 15:34 README.md drwxr-xr-x 2 sms185 prof 5 Aug 18 15:34 scripts drwxr-xr-x 2 sms185 prof 594 Aug 18 15:34 simulation ``` ] - `[sms185@numeric1 cl_demo]$` is the prompt - `ls` is the command, list directory contents in this case - `-l` is a short flag / option, `l` here means long listing format - `--all` is a long flag / option, `--all` is equivalent to `-a` - `./` is the argument, `./` here refers to the current directory General structure: `command [options] [arguments]`. To get help, input `man [command]` in the terminal. ```bash man ls ``` --- ## Parse the result ```bash [sms185@numeric1 cl_demo]$ ls -l --all ./ total 88 drwxr-xr-x 6 sms185 prof 7 Aug 18 15:34 . drwxr-xr-x 37 sms185 prof 63 Aug 18 15:34 .. *drwxr-xr-x 2 sms185 prof 5 Aug 18 15:34 data drwxr-xr-x 8 sms185 prof 13 Aug 18 15:34 .git -rw-r--r-- 1 sms185 prof 156 Aug 18 15:34 README.md drwxr-xr-x 2 sms185 prof 5 Aug 18 15:34 scripts drwxr-xr-x 2 sms185 prof 594 Aug 18 15:34 simulation ``` .small-text[ | d | rwx | r-x | r-x | 2 | sms185 | prof | 5 | Aug 18 15:34 | data | |:-------------:|:--------------------:|:--------------------:|:------------------:|:----------------------------------:|:------:|:-----:|:---------------:|:----------------:|:----:| | directory | owner<br>permissions | group<br>permissions | everyone<br>permissions | links or<br>directories <br>inside | owner | group | size<br>(bytes) | date<br>modified | name | ] --- ## Parse the result ```bash [sms185@numeric1 cl_demo]$ ls -l --all ./ total 88 drwxr-xr-x 6 sms185 prof 7 Aug 18 15:34 . drwxr-xr-x 37 sms185 prof 63 Aug 18 15:34 .. drwxr-xr-x 2 sms185 prof 5 Aug 18 15:34 data drwxr-xr-x 8 sms185 prof 13 Aug 18 15:34 .git *-rw-r--r-- 1 sms185 prof 156 Aug 18 15:34 README.md drwxr-xr-x 2 sms185 prof 5 Aug 18 15:34 scripts drwxr-xr-x 2 sms185 prof 594 Aug 18 15:34 simulation ``` .small-text[ | - | rw- | r-- | r-- | 1 | sms185 | prof | 64 | Aug 18 15:34 | README.md | |:-------------:|:--------------------:|:--------------------:|:------------------:|:----------------------------------:|:------:|:-----:|:---------------:|:----------------:|:----:| | file | owner<br>permissions | group<br>permissions | everyone<br>permissions | links or<br>directories <br>inside | owner | group | size<br>(bytes) | date<br>modified | name | ] --- ## Copy (`cp`), move (`mv`), and delete (`rm`) Copy `cars.txt` and call the new file `cars2.txt`. .small-text[ ```bash [sms185@numeric1 cl_demo]$ cd data/ [sms185@numeric1 data]$ ls cars.txt diamonds.txt mtcars.txt [sms185@numeric1 data]$ cp cars.txt cars2.txt [sms185@numeric1 data]$ ls cars2.txt cars.txt diamonds.txt mtcars.txt ``` ] -- .small-text[ Move `cars2.txt` up one directory. ```bash [sms185@numeric1 data]$ mv cars2.txt ../ [sms185@numeric1 data]$ cd ../ [sms185@numeric1 cl_demo]$ ls cars2.txt data readme.md scripts simulation [sms185@numeric1 cl_demo]$ ``` ] -- .small-text[ Delete `cars2.txt` and verify it is gone. ```bash [sms185@numeric1 cl_demo]$ rm cars2.txt [sms185@numeric1 cl_demo]$ ls data readme.md scripts simulation ``` ] --- ## Wildcards and the shell (globs) These are characters that the shell will try to expand to match existing paths and files. - `*` matches any number of characters in a file name, including none - `?` matches any single character - `[ ]` range of characters that may match a single character at that position - `{ }` can be used to match filenames with multiple globbing patterns These are similar but distinct from regular expressions. Regular expressions will be covered when we got to string manipulation. <br> -- To find out how many simulation results we have for when `\(p\)` is 500 and `\(n\)` is 60 we can use the `*` wildcard. ```bash [sms185@numeric1 cl_demo]$ cd simulation/ [sms185@numeric1 simulation]$ ls -l testresultp500n60* | wc -l 98 ``` --- What do the below commands do? ```bash [sms185@numeric1 cl_demo]$ cd simulation/ [sms185@numeric1 simulation]$ ls testresultp1000n{30,60}rep?.txt ``` -- ```bash [sms185@numeric1 cl_demo]$ cd simulation/ [sms185@numeric1 simulation]$ ls testresultp1000n{30,60}rep?.txt testresultp1000n30rep1.txt testresultp1000n60rep1.txt testresultp1000n30rep2.txt testresultp1000n60rep2.txt testresultp1000n30rep3.txt testresultp1000n60rep3.txt testresultp1000n30rep4.txt testresultp1000n60rep4.txt testresultp1000n30rep5.txt testresultp1000n60rep5.txt testresultp1000n30rep6.txt testresultp1000n60rep6.txt testresultp1000n30rep7.txt testresultp1000n60rep7.txt testresultp1000n30rep8.txt testresultp1000n60rep8.txt testresultp1000n30rep9.txt testresultp1000n60rep9.txt ``` --- ## Other useful commands | Command | Use | Example | |------------:|--------------------------------|---------------------| | `cd ../` | move up one directory | `cd ../` | | `cd ../../` | move up two directories | `cd ../ ../` | | `man` | show the manual for a command | `man mkdir` | | `mkdir` | create a directory | `mkdir new_folder` | | `rmdir` | remove a directory | `rmdir new_folder` | | `touch` | create a file | `touch get_data.R` | | `locate` | find a file | `locate -n 5 "*.R"` | | `clear` | clear terminal window | `clear` | | `history` | print history of commands used | `history` | | `htop` | process viewer (Linux) | `htop -u sms185` | <br> Use commands `rm` and `rmdir` with caution. Never run `rm -rf /`. --- ## Exercises 1. Navigate to directory `cl_demo/`. Explore and map out everything in `cl_demo/`. Draw a tree diagram as in the slide titled Path Diagram. <br><br> 2. Create two new folders in `cl_demo/simulation/` with names `p500` and `p1000`. Move all simulation results with parameter `\(p\)` being 500 to folder `p500/`. Similarly, move all simulation results with parameter `\(p\)` being 1000 to folder `p1000/`. --- class: inverse, center, middle # git and GitHub --- ## Why version control? .pull-left[ - Simple formal system for tracking all changes to a project - Time machine for your projects + Track blame and/or praise + Remove the fear of breaking things - Learning curve is steep, but when you need it you *REALLY* need it ] .pull-right[ ![](images/local_vc_system.png) ] --- ## Why git? .pull-left[ - Distributed + Work online or offline + Collaborate with large groups - Popular and Successful + Active development + Shiny new tools and ecosystems + Fast - Tracks any type of file - Branching + Smarter merges ] .pull-right[ ![](images/distributed_vc_system.png) ] --- ## Verifying git exists git is already set-up on the DSS servers. You can see this by running the below commands in your terminal tab ```bash [sms185@numeric1 ~]$ git --version git version 2.20.1 ``` ```bash [sms185@numeric1 ~]$ which git /usr/bin/git ``` <br> To install git (if needed) and connect git, GitHub and RStudio on your own computer follow the directions in [Happy Git and GitHub for the useR](https://happygitwithr.com/). --- class: inverse, center, middle # git and GitHub live demo --- ## Configure git Enter the following in your terminal to tell git who you are, what editor you want to use, and to store your GitHub credentials. ```bash git config --global user.name "full name" git config --global user.email "email associated with GitHub" git config --global push.default simple git config --global core.editor [editor-of-choice] git config --global credential.helper 'cache --timeout=600000' ``` *On DSS my editor of choice is vim; on my own computer my editor of choice is* *Sublime Text 3.* You will need to do this configuration on each machine in which you choose to use git. For windows users, the last line should be ```bash git config --global credential.helper wincred ``` --- ## Configure git verification To verify you configured git correctly, run ```bash *[sms185@numeric1 ~]$ git config --global -l user.name=Shawn Santo user.email=shawn.santo@duke.edu core.editor=vim push.default=simple credential.helper=cache --timeout=600000 ``` You should see output similar to above. -- .small-text[ Using command `git config --global -l` on Windows: ```bash user.name=Shawn Santo user.email=shawn.santo@duke.edu core.editor='c:/program files/sublime text 3/sublime_text.exe' -w credential.helper=wincred push.default=simple ``` ] .small-text[ Using command `git config --global -l` on Mac: ```bash credential.helper=osxkeychain user.name=Shawn Santo user.email=shawn.santo@duke.edu core.editor=/Applications/Sublime\ Text.app/Contents/SharedSupport/bin/subl -n -w push.default=simple credential.helper=cache --timeout=600000 ``` ] --- ## Version control best practices - Commit early, often, and with complete code. - Write clear and concise commit summary messages. - Test code before you commit. - Use branches. - Communicate with your team. --- ## git clone, status, add, commit, push .small-text[ | git Command | Description | |-----------------------------:|:-----------------------------------------------------| | `git clone <repo>` | Clone repo located at `<repo>` onto local machine | | `git status` | List which files are staged, unstaged, and untracked | | `git diff` | Show unstaged changes | | `git add <directory/file>` | Stage changes of `<directory/file>` | | `git commit -m "<message>"` | Commit staged snapshot with a summary `<message>` | | `git push <remote> <branch>` | Push the `<branch>` to `<remote>` | ] <br/> These commands are enough to focus on for now as you work on individual assignments and projects. We'll soon add more that will be useful in team-based projects. --- ## References 1. Git - Book. (2021). https://git-scm.com/book/en/v2. 2. Nokia Bell Labs: The invention of Unix. (2019). https://www.bell-labs.com/var/articles/invention-unix/.
